Sony ILME-FR7 Full-Frame Interchangeable Lens PTZ Camera

Sony
Abel Code: SO-ILME-FR7
Mfr. Code: ILMEFR7.UC2
Not Available Online
Special Order Only
This is a special order item. You will be charged upon placing your order, which is non-cancelable and non-returnable.
Description
The Sony FR7 Cinema Line Full-Frame Interchangeable Lens PTZ Robotic Camera has 15+ stop dynamic range, 4K (QFHD) high-frame-rate 120fps, Fast Hybrid & Real-time Eye AF, and S-Cinetone color science.
Key Highlights
  • 4K Full-Frame Sensor
  • Sony E-Mount Lens Interchangeability
  • 12G-SDI, HDMI & Streaming Output
Deposit Info
Reserve your item with a deposit which will be applied to your final sales price.
Full Price: $9,699.99
? Deposit:
A deposit reserves this item and will be applied to the final purchase price. See product page for details.
$969.99
Wishlist
Overview

Overview

The Sony ILME-FR7 is the world’s first PTZ (Pan-Tilt-Zoom) camera to combine E-mount lens interchangeability and a full-frame, 4K (10.3MP) Exmor R image sensor with 15+ stops of dynamic range and a Base Sensitivity setting that allows ISO to be expanded up to 409,600 when shooting in low light.

Key Features:

  • World’s first full-frame interchangeable lens camera with pan/tilt/zoom (PTZ) functionality
  • Remotely controlled pan/tilt/zoom mechanism with up to 100 camera presets
  • Compatible with 70 E-mount lenses ranging from 12mm to 1200mm, including power zoom models
  • 15mm LWS (Lightweight) rod support
  • Web App for control by tablet or PC via web browser, or with optional RM-IP500 (sold separately) for precise joystick control
  • High sensitivity up to ISO 409,600 and 15+ stop dynamic range, selectable 800 or 12,800 base ISO
  • In-camera Slow & Quick motion from 1 fps up to 120 fps 4K (QFHD) / 240 fps FHD
  • Fast Hybrid AF w/ 627 phase-detection AF points and Real time Eye-AF
  • Remotely controllable continuously variable electronic ND filter (1/4 to 1/128)
  • Custom and Cine EI mode shooting modes to match creative workflows
  • Professional connectivity; up to 12G SDI, HDMI A, XLR input, TC, GENLOCK
  • 4:2:2 10-bit XAVC-I (Intra), XAVC-L (Long GOP) and 16-bit RAW output
  • S-Cinetone for rich cinematic images right out of the camera
  • Picture Profiles incl. HLG12, S-Log3 w/ S-Gamut3, S-Gamut3.Cine
  • Breathing Compensation suppresses unintended image shifts (with compatible lenses)
  • Up to 100 programmable quick access preset positions
  • 12G SDI BNC output/ HDMI type A video output
  • Compatible with optical output module (sold separately) for low-loss transfer over long distances
  • XLR 5-pin 2-Channel audio input connector
  • Professional connectivity with TC input, GENLOCK and Option connectors
  • RTSP / NDI|HX / SRT IP streaming (with optional license from NewTek)
  • Tally lights facilitate multi-camera operation
  • Dual card slots, both compatible w/ CFexpress Type A, SDXC UHS-I/II
  • Dedicated accessory ceiling mount bracket CIB-PCM1 (sold separately)

Interchangeable Optics

Compatibility with Sony’s wide range of E-mount lenses* enables the FR7 to break through location and space limitations while maintaining the cinematic look and operability that have made Sony digital cinema cameras leaders in the field. Versatile connectivity and efficient multi-camera workflow support further enhance the user experience. Power zoom models can be controlled remotely and provide unique framing flexibility.

*NOTE: Some E-mount lenses (e.g., SEL100400GM, SEL200600G, SEL400F28GM, and SEL600F40GM) are not compatible with pan and tilt operation on the FR7. Refer to Sony’s support site for compatibility information.

4K Internal Recording

The FR7 is capable of 4K internal recording, encoding 10-bit depth and 4:2:2 color sampling with either Full-HD Long-GOP or 4K All Intra compression. This makes it possible to push your color grades further, stretching video out for ultimate HDR realism while still retaining natural gradation.

Internal Slow-Motion Capture

The FR7 allows internal slow-motion capture at QFHD resolution and a high 120 fps frame rate. 120 fps footage can be recorded at the camera’s highest quality XAVC-I 4:2:2 10-bit Class 300. Full HD can be recorded at 240 fps allowing 10x slow motion (24p recording).

High Sensitivity and Dynamic Range

In addition to the FR7’s Base Sensitivity setting for low light shooting, it also features a Cine EI mode where base sensitivity can be set to either ISO 800 or ISO 12,800 to match lighting conditions, making it possible to minimize noise while maintaining a consistent look. The FR7’s wide 15+ stop dynamic range prevents blown highlights and blocked shadows. The inclusion of Sony's acclaimed S-Cinetone look, allows beautiful images to be achieved directly in-camera. S-Cinetone is optimized for natural skin tones and mid-range colors, with gentle highlight roll-off, for impressive subject depiction and camera-matching and powerful post-production possibilities.

Hybrid Log-Gamma HDR Profile

The included HLG (Hybrid Log-Gamma) HDR picture profile, complete with the wide-gamut BT.2020 color space, can be used for direct HDR (HLG) playback on compatible TVs. S-Log3 gamma curves are available, with S-Log3 designed for better reproduction of gradations from shadows to the mid-grey range (18% grey). Two color gamut settings (S- Gamut3, and S-Gamut3.Cine) make it easy to match the colors of footage shot with Sony's Cinema Line Cameras.

Variable Electronic ND Filter

Sony’s integrated, remotely controllable ND filter allows seamless ND adjustment from 1/4 to 1/128 so that exposure can be varied while keeping the aperture constant for consistent depth of field. Variable ND in auto perfectly exposes images without affecting the depth of field, shutter angle or ISO, letting you achieve ideal exposure even during changing lighting conditions. Remote control is also possible, allowing exposure control at a distance from the camera.

Fast Hybrid Autofocus

Fast Hybrid AF locks onto the subject quickly and tracks tenaciously, with 627 selectable phase-detection AF points that cover almost the entire image area (approx. 94% vertical and 95% horizontal). The camera’s BIONZ XR engine can process a huge volume of subject data in real time for precise, high-density focus analysis. Fast Hybrid AF and pan/tilt/zoom functionality combine to focus on even fast-moving subjects precisely and smoothly over a wide area, even when a shallow depth of field is used.  The advanced real-time processing realizes unprecedented detection performance for pinpoint eye focus even when subjects are looking down or up at steep angles, allowing the operator to concentrate fully on composing the best shot. This high-performance AF is available when shooting 4K 120p movies too. Touch Tracking can be used to initiate Real-time Tracking on the desired subject when using the FR7 web application, with Real-time Eye AF if an eye is detected. Maximum AF points can vary according to the recording modes. NOTE: Requires use of an AF-compatible lens.

Flexible Camera Mounting Options

With its integrated and remotely controllable pan/tilt mechanism, FR7 can be mounted on a tripod, the ceiling, or in other locations that provide limited access, allowing subjects to be recorded from unique viewpoints. Pan and tilt speed can be continuously varied from 0.02 degrees/sec to 60 degrees/sec, supporting a wide range of precise camera movements. The pan angle range is from -170° to +170°, and the tilt angle range is from -30° to +195° when used in upright orientation (or from -210° to +15° inverted).

Web Application Control

A new, dedicated web application enables control of pan, tilt, zoom, focus, record, playback, and all camera settings from a tablet or computer web browser. This provides easy, versatile remote control for situations where the camera is mounted on a ceiling or other hard-to-access location.

Precise, Scalable Remote Control with the RM-IP500

FR7 is compatible with Sony’s RM-IP500 remote controller for multi-camera production with precise joystick operation, further expanding creative potential. Speed adjustment knobs allow pan, tilt, zoom, focus, speed adjustment to match the subject and application. Zoom can be controlled either via the joystick or a seesaw lever, to match operator needs. A single RM-IP500 unit can remotely control up to 100 FR7 cameras (10 groups of 10 cameras). Up to 100 camera position presets can be memorized (presets include camera direction, zoom, and focus, and can be recalled at the touch of a button).

HDMI Type A & 12G SDI BNC Output

It is possible to output video as a 12G, 6G, 3G, or HD-SDI signal, and the camera can also output in 16-bit RAW format when the appropriate setting is selected (100/120p recording and proxy recording are not supported in 16-bit RAW). There’s also the option of either a clean HDMI output, for external recording, or overlaid with status and settings for monitoring. Additionally, an optional SFP+ module (sold separately) can be used to convert the camera's SDI output to optical format for low-loss transfer over long distances.

XLR 5-pin 2-Channel Audio Input

This connector receives the output from an external microphone or audio device. Audio CH-1 and CH-2 are received via a single 5-pin connector.

Professional Connectivity with TC Input, GENLOCK and Option Connectors

To support professional synchronization, BNC connectors for Timecode input and GENLOCK are provided as well as an OPTION connector to coordinate tally light signals with an external device.

RTSP / NDI|HX / SRT IP Streaming

RTSP streaming allows the video output from one camera to be simultaneously distributed to up to five viewers. SRT enables high-quality, low-latency video transfer even in unstable network conditions. NDI|HX enables a network connection to NDI compatible devices such as switchers and media servers, supporting efficient live video production using Internet protocols. NOTE: An NDI|HX Upgrade must be purchased from NewTek.

Integrated Tally Lights

In a multi-camera shoot, tally lights indicate which camera is currently in use, helping to facilitate smooth operation. A red tally light can indicate the current on-air camera while a green tally light can indicate a camera in preview, ready to be switched on-air next.

Dual Media Card Slots

A rare feature in a PTZ camera, the FR7 features dual media slots that support CFexpress Type A and SDXC memory cards. Slots A and B both support CFexpress Type A memory cards as well as UHS-II/UHS-I memory cards for fast transfer of large volumes of data. The ability to record exposure settings and other metadata with high-quality XAVC-I footage makes the FR7 an excellent choice for a wide variety of video production applications.

Dedicated Ceiling Mount Bracket

The FR7 is compatible with the CIB-PCM1 accessory ceiling mount bracket (sold separately) for easy overhead setup.  The “Ceiling” option in the Web App flips the control directions, for natural operation even with the camera mounted upside down.



Specifications:

MassApprox. 10 lb 2.3 oz
Approx. 13 lb 3.6 oz(with SELP28135G LENS)
Dimensions (W x H x D)[[F_WI0001]]Approx. 9 x 11 1/2 x 9 1/4 inch(body without protrusions)
Power RequirementsDC 19.5 V
PoE++(IEEE802.3bt Type 4 Class 8 compliant) 41.1 V~57.0 V
Power Consumption≦80 W(DC 19.5 V)
≦71.3 W(PoE++)
Operating Temperature0 °C to 40 °C
32 °F to 104 °F
Storage Temperature-20 °C to +60 °C
-4 °F to +140 °F
Ceiling MountYes (with Ceiling Bracket option)
Tally LampLeft(x1)/Right(x1), Red/Green
Recording Format (Video)[XAVC Intra]
XAVC-I DCI4K 59.94p mode:VBR, MAX bit rate 600 Mbps, MPEG-4 AVC/H.264
XAVC-I DCI4K 50p mode:VBR, MAX bit rate 500 Mbps, MPEG-4 AVC/H.264
XAVC-I DCI4K 29.97p mode:VBR, MAX bit rate 300 Mbps, MPEG-4 AVC/H.264
XAVC-I DCI4K 25p mode:VBR, MAX bit rate 250 Mbps, MPEG-4 AVC/H.264
XAVC-I DCI4K 24p mode:VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264
XAVC-I DCI4K 23.98p mode:VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 59.94p mode:VBR, MAX bit rate 600 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 50p mode:VBR, MAX bit rate 500 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 29.97p mode:VBR, MAX bit rate 300 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 25p mode:VBR, MAX bit rate 250 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 23.98p mode:VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 59.94p mode:CBG, MAX bit rate 222 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 50p mode:CBG, MAX bit rate 223 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 29.97p mode:CBG, MAX bit rate 111 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 25p mode:CBG, MAX bit rate 112 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 23.98p mode:CBG, MAX bit rate 89 Mbps, MPEG-4 AVC/H.264
[XAVC Long]
XAVC-L QFHD 29.97p/25p/23.98p mode:VBR, MAX bit rate 100 Mbps, MPEG-4 H.264/AVC
XAVC-L QFHD 59.94p/50p mode:VBR, MAX bit rate 150 Mbps, MPEG-4 H.264/AVC
XAVC-L HD 29.97p/25p/23.98p/59.94p/50p mode:VBR, MAX bit rate 50 Mbps, MPEG-4 H.264/AVC
XAVC-L HD 29.97p/25p/23.98p/59.94p/50p mode:VBR, MAX bit rate 35 Mbps, MPEG-4 H.264/AVC
Recording Format (Audio)LPCM 24 bits, 48 kHz, 4 channels
Recording Frame Rate[XAVC Intra]
XAVC-I DCI4K mode:4096 x 2160/59.94p, 50p, 29.97p, 23.98p, 25p, 24p
XAVC-I QFHD mode:3840 x 2160/59.94p, 50P, 29.97p, 23.98p, 25p
XAVC-I HD mode:1920 x 1080/59.94p, 50p, 29.97p, 23.98p, 25p
[XAVC Long]
XAVC-L QFHD mode:3840 x 2160/59.94p, 50p, 29.97p, 23.98p, 25p
XAVC-L HD 50 mode:1920 x 1080/59.94p, 50p, 29.97p, 23.98p, 25p
XAVC-L HD 35 mode:1920 x 1080/59.94p, 50p, 29.97p, 23.98p, 25p
Recording/Playback Time[XAVC Intra]
XAVC-I DCI4K/QFHD 59.94p
When using CEA-G160T (160 GB)
Approx. 30 minutes
When using CEA-G80T (80 GB)
Approx. 15 minutes
XAVC-I DCI4K/QFHD 50p
When using CEA-G160T (160 GB)
Approx. 36 minutes
When using CEA-G80T (80 GB)
Approx. 17 minutes
XAVC-I DCI4K/QFHD 29.97p
When using CEA-G160T (160 GB):
Approx. 60 minutes
When using CEA-G80T (80 GB)
Approx. 29 minutes
XAVC-I DCI4K/QFHD 25p
When using CEA-G160T (160 GB):
Approx. 71 minutes
When using CEA-G80T (80 GB)
Approx. 35 minutes
XAVC-I DCI4K 24p
When using CEA-G160T (160 GB):
Approx. 74 minutes
When using CEA-G80T (80 GB)
Approx. 36 minutes
XAVC-I DCI4K/QFHD 23.98p
When using CEA-G160T (160 GB):
Approx. 74 minutes
When using CEA-G80T (80 GB)
Approx. 36 minutes
XAVC-I HD 59.94p
When using CEA-G160T (160 GB):
Approx. 78 minutes
When using CEA-G80T (80 GB)
Approx. 38 minutes
XAVC-I HD 50p
When using CEA-G160T (160 GB):
Approx. 78 minutes
When using CEA-G80T (80 GB)
Approx. 38 minutes
XAVC-I HD 29.97p
When using CEA-G160T (160 GB):
Approx. 150 minutes
When using CEA-G80T (80 GB)
Approx. 74 minutes
XAVC-I HD 25p
When using CEA-G160T (160 GB):
Approx. 150 minutes
When using CEA-G80T (80 GB)
Approx. 74 minutes
XAVC-I HD 23.98p
When using CEA-G160T (160 GB):
Approx. 185 minutes
When using CEA-G80T (80 GB)
Approx. 91 minutes
[XAVC Long]
XAVC-L QFHD 29.97p/25p/23.98p
When using CEA-G160T (160 GB):
Approx. 170 minutes
When using CEA-G80T (80 GB)
Approx. 86 minutes
XAVC-L QFHD 59.94p/50p
When using CEA-G160T (160 GB):
Approx. 115 minutes
When using CEA-G80T (80 GB)
Approx. 57 minutes
XAVC-L HD 50 /29.97p/25p/23.98p/59.94p/50p
When using CEA-G160T (160 GB):
Approx. 320 minutes
When using CEA-G80T (80 GB)
Approx. 155 minutes
XAVC-L HD 35 29.97p/25p/23.98p/59.94p/50p
When using CEA-G160T (160 GB):
Approx. 430 minutes
When using CEA-G80T (80 GB)
Approx. 210 minutes
Recording Format (Proxy Audio)XAVC Proxy: AAC-LC, 128 kbps, 2 channels
Recording Format (Proxy Video)XAVC Proxy: AVC/H.264 High Profile 4:2:0 Long GOP, VBR
1920 x 1080, 9 Mbps
Lens MountE-mount
Imaging Device (Type)35mm full frame (35.6 x 23.8 mm), Exmor R CMOS sensor
Number of pixels (total)Approx. 12.9 megapixels
Number of pixels (effective)Approx. 10.3 megapixels
Built-in Optical FiltersClear, linear variable ND(1/4ND to 1/128ND)
ISO SensitivityISO 800/12800 (Cine EI mode, D55 Light source)
FocusTypeFast Hybrid AF (phase-detection AF / contrast-detection AF)
Focus point627 points
Focus areaWide / Zone / Flexible Spot
Other focus featuresEye AF (Human)
Other focus featuresAF Subj. Shift Sensitivity
Other focus featuresAF Transition Speed
Other focus featuresFace detection (Face/Eye Priority, Face/Eye Only AF )
Other focus featuresReal-time Tracking AF
Output FormatSDI4096 x 2160 / 59.94p, 50p, 29.97p, 25p, 24p, 23.98p, 3840 x 2160 / 59.94p, 50p, 29.97p, 25p, 23.98p, 1920 x 1080 / 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 24p, 23.98p, 29.97PsF, 25PsF
HDMI4096 x 2160 / 59.94p, 50p, 29.97p, 25p, 24p, 23.98p, 3840 x 2160 / 59.94p, 50p, 29.97p, 25p, 23.98p, 1920 x 1080 / 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 24p, 23.98p, 720 x 480 / 59.94p, 720 x 576 / 50p
Clear Image ZoomQFHD/4K: 1.5x, HD: 2x
Shutter Speed64 frame to 1/8000 sec
Slow and Quick Motion FunctionXAVC-I
4096 x 2160
1 to 60 frames (59.94/50/29.97/25/24/23.98)
XAVC-I/L
3840 x 2160
1 to 60, 100, 120 frames (59.94/50/29.97/25/23.98)
1920 x 1080
1 to 60, 100, 120, 150, 180, 200, 240 frames (59.94/50/29.97/25/23.98)
White BalancePreset, Memory A(2000K-15000K)/ATW
Gain-3 to 30 dB (every 1dB), AGC
Gamma CurveSDR Mode :S-Cinetone, Standard, Still, ITU709
HDR mode : HLG_Live, HLG_Natural
Latitude15+ stop
Pan/Tilt AnglePan: -170 deg. ~170 deg.
Tilt: -30 deg. ~195 deg.
Pan/Tilt SpeedPan: 0.02 deg. to 60 deg./s
Tilt: 0.02 deg. to 60 deg./s
QuietnessNC35 or less
Preset Position100
Audio InputXLR-type 5-pin (female) (x1),
line/mic/mic +48 V selectable
Mic Reference: -30 to -80 dBu
SDI OutputBNC (x1),
12G-SDI, 6G-SDI, 3G-SDI(Level A/B), HD-SDI
HDMI OutputType-A connector(x1)
Genlock InputBNC (x1), 1.0 Vp-p, 75 Ω
Optical OutputSFP+ compliant
video is same as SDI, video output only
DC InputDC jack(x1)
NetworkRJ-45(LAN) (x1), 1000BASE-T
Remote ControlRJ-45(OPTION) (x1)
Red Tally IO/Green Tally IO
IR Remote ControlYes
TC Input/TC OutputBNC (x1), TC IN only
ProtocolsIPv6TCP, UDP, ICMPv6, HTTP, HTTPS, DHCPv6, DNS, mDNS, RTP/RTCP, RTSP, SRT, FTP, FTPS
IPv4TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, mDNS, RTP/RTCP, RTSP, VISCA over IP, SRT, NDI|HX, FTP, FTPS
IP StreamVideo Resolution4096 x 2160, 3840 x 2160, 2048 x 1080, 1920 x 1080, 1280 x 720, 640 x 360
Compression FormatH.264: High/Main/Baseline Profile
H.265: Main/Main10 Profile
Maximum Frame RateH.264: 59.94fps
H.265: 59.94fps
Bitrate Control ModeCBR/VBR
Range of Bitrate Setting512 Kbps~80 Mbps
NDI|HX capabilityYes Option
(need to attach a license)
Supported operation systemsWindowsWindows 10 or later
MacmacOS 10.15 or later
iPadiPadOS 15 or later
AndroidAndroid 12 or later
Supported web browsersWindowsGoogle Chrome
MacGoogle Chrome、Safari
iPadGoogle Chrome、Safari
AndroidGoogle Chrome
TypeCFexpress Type A / SD card (x2)
Supplied AccessoriesBody cap
HDMI cable fixing plate
REMOTE COMMANDER (RMT-RC1)
AC Adaptor
Power cord

Screen ReaderYes (Language: English, Speed: 7 steps, Volume:15 steps)
This function is available only when the menu language is set to English on North American models. (As of the release date)

What's in the Box

  • Sony FR7 Cinema Line Full-Frame Interchangeable Lens PTZ Robotic Camera
Specifications

Specifications

Key Highlights

  • 4K Full-Frame Sensor
  • Sony E-Mount Lens Interchangeability
  • 12G-SDI, HDMI & Streaming Output
  • 15+ stops dynamic range
  • 15mm LWS rod support

Camera Lens System

Camera Lens Mount:
E
Interchangeable Mount:
Yes
Finance Services

Finance Services

Customized financing from pros who understand this industry and your unique needs.

AbelCare

AbelCare

Get access to our tech services, support and training, on your terms, when you need it most.

AbelCine - Contact Sales

Have a question about Sales?


Contact us
